9/22/231415Z
|
!FDC 3/3403 SDC PART 1 OF 3 ODP WILLIAMSON/SODUS,
WILLIAMSON/SODUS, NY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1A...
TAKEOFF OBSTACLE NOTES: NOTE: RWY 10: TREES, VEHICLES ON ROAD,
POLES, BUILDING BEGINNING 24 FT FROM DER, 45 FT RIGHT OF
CENTERLINE, UP TO 98 FT AGL/516 FT MSL. TREES BEGINNING 38 FT FROM
DER, 272 FT LEFT OF CENTERLINE, UP TO 488 FT MSL. TREES BEGINNING
154 FT FROM DER, 279 FT LEFT OF CENTERLINE, UP TO 493 FT MSL.
TREES, VEHICLES ON ROAD, ELEVATOR, GRAIN ELEVATOR, POLE, BUILDINGS
BEGINNING 259 FT FROM DER, 16 FT LEFT OF CENTERLINE, UP TO 67 FT
AGL/498 FT MSL. TREES BEGINNING 1007 FT FROM DER, 65 FT RIGHT OF
CENTERLINE, UP TO 84 FT AGL/518 FT MSL. TREES BEGINNING 1231 FT
FROM DER, 9 FT RIGHT OF CENTERLINE, UP TO 535 FT MSL. TREES
BEGINNING 2102 FT FROM DER, 251 FT LEFT OF CENTERLINE, UP TO 502 FT
MSL. TREES BEGINNING 2236 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP
TO 83 FT AGL/507 FT MSL. TREES BEGINNING 2563 FT FROM DER, 88 FT
RIGHT OF CENTERLINE, UP TO 86 FT AGL/536 FT MSL. TREES BEGINNING
2780 FT FROM DER, 49 FT RIGHT OF CENTERLINE, UP TO 542 FT MSL.
TREES BEGINNING 2934 FT FROM DER, 25 FT RIGHT OF CENTERLINE, UP TO
543 FT MSL. TREES BEGINNING 2938 FT FROM DER, 187 FT LEFT OF
CENTERLINE, UP TO 93 FT AGL/509 FT MSL. TREES BEGINNING 2977 FT
FROM DER, 15 FT LEFT OF CENTERLINE, UP TO 95 FT AGL/511 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309221415-2509221415EST
END PART 1 OF 3
!FDC 3/3403 SDC PART 2 OF 3 ODP WILLIAMSON/SODUS,
WILLIAMSON/SODUS, NY.
TREES BEGINNING 2991 FT FROM DER, 70 FT RIGHT OF CENTERLINE, UP TO
553 FT MSL. TREES BEGINNING 3031 FT FROM DER, 7 FT RIGHT OF
CENTERLINE, UP TO 573 FT MSL. TREES BEGINNING 3091 FT FROM DER, 102
FT RIGHT OF CENTERLINE, UP TO 583 FT MSL. TREES BEGINNING 3132 FT
FROM DER, ON AND RIGHT OF CENTERLINE, UP TO 598 FT MSL. TREES
BEGINNING 3193 FT FROM DER, 22 FT RIGHT OF CENTERLINE, UP TO 607 FT
MSL. TREES BEGINNING 3291 FT FROM DER, 101 FT RIGHT OF CENTERLINE,
UP TO 611 FT MSL. TREES, UTILITY LIGHTS BEGINNING 3352 FT FROM DER,
112 FT RIGHT OF CENTERLINE, UP TO 619 FT MSL. TREES, UTILITY LIGHT
BEGINNING 3488 FT FROM DER, 223 FT RIGHT OF CENTERLINE, UP TO 78 FT
AGL/631 FT MSL. TREES, UTILITY LIGHTS, POLE, VEHICLE ON ROAD
BEGINNING 3800 FT FROM DER, 800 FT RIGHT OF CENTERLINE, UP TO 69 FT
AGL/636 FT MSL. TREES BEGINNING 1 NM FROM DER, 1696 FT RIGHT OF
CENTERLINE, UP TO 663 FT MSL. TREES BEGINNING 1.1 NM FROM DER, 1770
FT RIGHT OF CENTERLINE, UP TO 669 FT MSL. TREES BEGINNING 1.3 NM
FROM DER, 510 FT LEFT OF CENTERLINE, UP TO 641 FT MSL. TREES, TOWER
BEGINNING 1.4 NM FROM DER, 256 FT LEFT OF CENTERLINE, UP TO 64 FT
AGL/668 FT MSL. TREES BEGINNING 1.5 NM FROM DER, 416 FT LEFT OF
CENTERLINE, UP TO 85 FT AGL/679 FT MSL. TOWERS BEGINNING 1.6 NM
FROM DER, 371 FT LEFT OF CENTERLINE, UP TO 121 FT AGL/715 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309221415-2509221415EST
END PART 2 OF 3
!FDC 3/3403 SDC PART 3 OF 3 ODP WILLIAMSON/SODUS,
WILLIAMSON/SODUS, NY.
NOTE: RWY 28: TREES, TERRAIN, VEGETATION, POLE, FENCES, VEHICLES ON
ROAD, BUILDINGS BEGINNING 10 FT FROM DER, 1 FT LEFT OF CENTERLINE,
UP TO 107 FT AGL/532 FT MSL. TREES, BUILDINGS, POLES, FENCES,
VEHICLES ON ROAD BEGINNING 70 FT FROM DER, 10 FT RIGHT OF
CENTERLINE, UP TO 513 FT MSL. TREES BEGINNING 391 FT FROM DER, 1 FT
RIGHT OF CENTERLINE, UP TO 516 FT MSL. TREES BEGINNING 431 FT FROM
DER, 64 FT RIGHT OF CENTERLINE, UP TO 90 FT AGL/519 FT MSL. TREES
BEGINNING 460 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO 93 FT
AGL/524 FT MSL. TREES BEGINNING 470 FT FROM DER, 1 FT RIGHT OF
CENTERLINE, UP TO 106 FT AGL/531 FT MSL. TREES BEGINNING 2676 FT
FROM DER, 148 FT LEFT OF CENTERLINE, UP TO 537 FT MSL. TREES
BEGINNING 2694 FT FROM DER, 83 FT LEFT OF CENTERLINE, UP TO 541 FT
MSL. TREES BEGINNING 2763 FT FROM DER, 312 FT LEFT OF CENTERLINE,
UP TO 112 FT AGL/549 FT MSL. TREES BEGINNING 4103 FT FROM DER, 957
FT LEFT OF CENTERLINE, UP TO 552 FT MSL..
ALL OTHER DATA REMAINS AS PUBLISHED. 2309221415-2509221415EST
END PART 3 OF 3
|
