3/3/232206Z
|
!FDC 3/2597 SKI PART 1 OF 2 ODP SAC CITY MUNI, SAC CITY, IA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: NOTE: RWY 14: TREES BEGINNING 57 FT FROM
DER, 73 FT LEFT OF CENTERLINE, UP TO 50 FT AGL/1300 FT MSL. TREES
BEGINNING 70 FT FROM DER, 12 FT RIGHT OF CENTERLINE, UP TO 50 FT
AGL/1307 FT MSL. TREES 2429 FT FROM DER, 1125 FT LEFT OF
CENTERLINE, 50 FT AGL/1304 FT MSL.
RWY 18: BUILDING 640 FT FROM DER, 631 FT RIGHT OF CENTERLINE, 23 FT
AGL/1259 FT MSL. TREE 931 FT FROM DER, 667 FT RIGHT OF CENTERLINE,
1293 FT MSL. TREES BEGINNING 1020 FT FROM DER, 657 FT RIGHT OF
CENTERLINE, UP TO 1299 FT MSL.
RWY 32: BUILDING 13 FT FROM DER, 344 FT RIGHT OF CENTERLINE, 26 FT
AGL/1276 FT MSL. BUILDING, POLE BEGINNING 71 FT FROM DER, 262 FT
RIGHT OF CENTERLINE, UP TO 31 FT AGL/1280 FT MSL. TREES BEGINNING
98 FT FROM DER, 298 FT LEFT OF CENTERLINE, UP TO 50 FT AGL/1320 FT
MSL. NAVAID, BUILDING, TREE, VEHICLE ON ROAD BEGINNING 207 FT FROM
DER, 298 FT RIGHT OF CENTERLINE, UP TO 55 FT AGL/1305 FT MSL. TREES
BEGINNING 353 FT FROM DER, 22 FT LEFT OF CENTERLINE, UP TO 50 FT
AGL/1323 FT MSL. TREES, TREE BEGINNING 609 FT FROM DER, 3 FT RIGHT
OF CENTERLINE, UP TO 50 FT AGL/1327 FT MSL.
RWY 36: TERRAIN 81 FT FROM DER, 376 FT LEFT OF CENTERLINE, 1250 FT
2303032206-2503312206EST
END PART 1 OF 2
!FDC 3/2597 SKI PART 2 OF 2 ODP SAC CITY MUNI, SAC CITY, IA.
MSL. BUILDING, GENERAL UTILITY, POLE BEGINNING 148 FT FROM DER, 333
FT LEFT OF CENTERLINE, UP TO 26 FT AGL/1276 FT MSL. NAVAID, TREE,
VEHICLE ON ROAD BEGINNING 374 FT FROM DER, 162 FT LEFT OF
CENTERLINE, UP TO 55 FT AGL/1305 FT MSL. TREE 2214 FT FROM DER,
1012 FT LEFT OF CENTERLINE, 1306 FT MSL. TREES BEGINNING 2384 FT
FROM DER, 664 FT LEFT OF CENTERLINE, UP TO 1318 FT MSL.
2303032206-2503312206EST
END PART 2 OF 2
|
