8/25/231253Z
|
!FDC 3/1190 SRE PART 1 OF 3 ODP SEMINOLE MUNI, SEMINOLE, OK.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
CHANGE TAKEOFF OBSTACLE NOTES TO READ: NOTE: RWY 16, VEHICLE ON
ROAD BEGINNING 3 FT FROM DER, 265 FT LEFT OF CENTERLINE, UP TO 15
FT AGL/1004 FT MSL. TREES BEGINNING 9 FT FROM DER, 259 FT RIGHT OF
CENTERLINE, UP TO 38 FT AGL/1017 FT MSL. POLES, TREES BEGINNING 43
FT FROM DER, 36 FT LEFT OF CENTERLINE, UP TO 25 FT AGL/1011 FT MSL.
TREES BEGINNING 78 FT FROM DER, 78 FT RIGHT OF CENTERLINE, UP TO 65
FT AGL/1032 FT MSL. TREES BEGINNING 362 FT FROM DER, 32 FT LEFT OF
CENTERLINE, UP TO 25 FT AGL/1015 FT MSL. TREES BEGINNING 484 FT
FROM DER, 41 FT RIGHT OF CENTERLINE, UP TO 53 FT AGL/1037 FT MSL.
TREES BEGINNING 611 FT FROM DER, 13 FT LEFT OF CENTERLINE, UP TO 29
FT AGL/1020 FT MSL. TREE 839 FT FROM DER, 557 FT LEFT OF
CENTERLINE, 61 FT AGL/1022 FT MSL. TREES BEGINNING 924 FT FROM DER,
237 FT RIGHT OF CENTERLINE, UP TO 45 FT AGL/1038 FT MSL. POLE 976
FT FROM DER, 173 FT LEFT OF CENTERLINE, 42 FT AGL/1027 FT MSL.
TREES BEGINNING 1245 FT FROM DER, 245 FT RIGHT OF CENTERLINE, UP TO
48 FT AGL/1043 FT MSL.
NOTE: RWY 34, TREES BEGINNING 1 FT FROM DER, 168 FT LEFT OF
CENTERLINE, UP TO 33 FT AGL/1043 FT MSL.
TERRAIN BEGINNING 7 FT FROM DER, 448 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2308251253-2508251253EST
END PART 1 OF 3
!FDC 3/1190 SRE PART 2 OF 3 ODP SEMINOLE MUNI, SEMINOLE, OK.
1042 FT MSL. TREE 14 FT FROM DER, 440 FT LEFT OF CENTERLINE, 34 FT
AGL/1044 FT MSL. VEHICLE ON ROAD, FENCE, TREE BEGINNING 17 FT FROM
DER, 309 FT RIGHT OF CENTERLINE, UP TO 15 FT AGL/1055 FT MSL. TREES
BEGINNING 20 FT FROM DER, 137 FT LEFT OF CENTERLINE, UP TO 35 FT
AGL/1048 FT MSL. TREE 121 FT FROM DER, 453 FT RIGHT OF CENTERLINE,
20 FT AGL/1061 FT MSL.TREES, TERRAIN, FENCE, VEHICLE ON ROAD
BEGINNING 132 FT FROM DER, 392 FT RIGHT OF CENTERLINE, UP TO 23 FT
AGL/1062 FT MSL. TREES, VEHICLE ON ROAD BEGINNING 175 FT FROM DER,
450 FT LEFT OF CENTERLINE, UP TO 31 FT AGL/1053 FT MSL. TREE 195 FT
FROM DER, 464 FT RIGHT OF CENTERLINE, 23 FT AGL/1063 FT MSL. TREES,
VEHICLE ON ROAD, BUILDING, TERRAIN BEGINNING 201 FT FROM DER, 292
FT RIGHT OF CENTERLINE, UP TO 30 FT AGL/1068 FT MSL. TREE, VEHICLE
ON ROAD BEGINNING 324 FT FROM DER, 251 FT LEFT OF CENTERLINE, UP TO
34 FT AGL/1057 FT MSL. TREES, VEHICLE ON ROAD BEGINNING 451 FT FROM
DER, 144 FT LEFT OF CENTERLINE, UP TO 37 FT AGL/1058 FT MSL. TREE
484 FT FROM DER, 528 FT RIGHT OF CENTERLINE, 40 FT AGL/1081 FT MSL.
TREES, FENCE, WALL, TERRAIN, VEHICLE ON ROAD, BUILDING, POLE
BEGINNING 506 FT FROM DER, 7 FT RIGHT OF CENTERLINE, UP TO 44 FT
AGL/1082 FT MSL. TREES, VEHICLE ON ROAD BEGINNING 586 FT FROM DER,
93 FT LEFT OF CENTERLINE, UP TO 68 FT AGL/1071 FT MSL. TREE 1083 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2308251253-2508251253EST
END PART 2 OF 3
!FDC 3/1190 SRE PART 3 OF 3 ODP SEMINOLE MUNI, SEMINOLE, OK.
FROM DER, 695 FT LEFT OF CENTERLINE, 43 FT AGL/1074 FT MSL. TREE,
VEHICLE ON ROAD BEGINNING 1210 FT FROM DER, 43 FT LEFT OF
CENTERLINE, UP TO 44 FT AGL/1087 FT MSL. TREES, VEHICLE ON ROAD
BEGINNING 1234 FT FROM DER, 64 FT LEFT OF CENTERLINE, UP TO 48 FT
AGL/1091 FT MSL. TREES, POLE, VEHICLE ON ROAD BEGINNING 1364 FT
FROM DER, 4 FT LEFT OF CENTERLINE, UP TO 48 FT AGL/1095 FT MSL.
TREES, VEHICLE ON ROAD, POLES BEGINNING 1465 FT FROM DER, 9 FT LEFT
OF CENTERLINE, UP TO 46 FT AGL/1099 FT MSL. POLE, VEHICLE ON ROAD
BEGINNING 1927 FT FROM DER, 13 FT RIGHT OF CENTERLINE, UP TO 47 FT
AGL/1089 FT MSL. POLES, TREE BEGINNING 1953 FT FROM DER, 163 FT
RIGHT OF CENTERLINE, UP TO 47 FT AGL/1090 FT MSL. POLES, TREES
BEGINNING 1972 FT FROM DER, 33 FT RIGHT OF CENTERLINE, UP TO 35 FT
AGL/1092 FT MSL. POLES, TREES, BUILDING BEGINNING 2114 FT FROM DER,
21 FT LEFT OF CENTERLINE, UP TO 43 FT AGL/1101 FT MSL. TREE, POLES
BEGINNING 2279 FT FROM DER, ON CENTERLINE, UP TO 33 FT AGL/1093 FT
MSL. TREE, POLES BEGINNING 2516 FT FROM DER, 23 FT RIGHT OF
CENTERLINE, UP TO 42 FT AGL/1097 FT MSL. TREES BEGINNING 3030 FT
FROM DER, 228 FT RIGHT OF CENTERLINE, UP TO 39 FT AGL/1103 FT MSL.
TREE 3748 FT FROM DER, 757 FT RIGHT OF CENTERLINE, 64 FT AGL/1120
FT MSL..
ALL OTHER DATA REMAINS AS PUBLISHED. 2308251253-2508251253EST
END PART 3 OF 3
|
