KSTL
ST LOUIS LAMBERT INTL
PublicPUB

10 miles NW of ST LOUIS, MO
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 44' 55"N 90° 22' 12"W
617' MSL
1617' MSL
01W
JET A, 100LL
SAINT LOUIS (STL)
ST LOUIS
KANSAS CITY (ZKC)
5/16/24-6/13/24
KSTL VFR
1:51 AM CDT
Broken 16,000'
Broken 3,200'
10sm
71°F
60°F
29.88"Hg
010° 12kts
Gusts 21kts
AO2 SLP106 T02170156 $
KSTL 090651Z 01012G21KT 10SM BKN032 BKN160 22/16 A2988 RMK AO2 SLP106 T02170156 $
Add Your Business

KSTL FBOs

Promote Listing
Signature Aviation
UNICOM: 131.35
Phone: (314) 731-7111
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 6/6
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 8.79 7.00
Fuel Notes
Prices include tax
Promote Listing
ATS JetCenter
UNICOM: 122.95
Phone: (314) 895-8788
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Terminal Area Forecast

KSTL
Sun, 6/9 12:20 AM CDT
Sun, 6/9 1:00 AM CDT - Mon, 6/10 7:00 AM CDT
VFR
1:00 AM CDT - 4:00 PM CDT
Broken 25,000'
Scattered 3,000'
6sm
360° 5kts
VFR
4:00 PM CDT - 7:00 AM CDT
Scattered 25,000'
6sm
320° 6kts
KSTL 090520Z 0906/1012 36005KT P6SM SCT030 BKN250
   FM092100 32006KT P6SM SCT250
KSTL
Domestic
6/10/241130Z !STL 06/145 STL NAV ILS RWY 06 U/S 2406101130-2406102000
6/10/241130Z !STL 06/144 STL NAV ILS RWY 24 U/S 2406101130-2406102000
6/9/240049Z !STL 06/187 STL TWY N BTN TWY F AND APCH END RWY 24 CLSD 2406090049-2406092359
6/9/240049Z !STL 06/186 STL TWY N RUNUP PAD CLSD 2406090049-2406092359
6/8/241944Z !STL 06/182 STL RWY 12R/30L CLSD EXC XNG AND TAX 2406081944-2407312359
6/6/241128Z !STL 06/109 STL OBST CRANE (ASN 2023-ACE-4475-NRA) 384518N0902206W (0.4NM NNE STL) 780FT (250FT AGL) FLAGGED AND LGTD 2406061128-2406302359
6/5/241907Z !STL 06/099 STL APRON TXL C SHOULDER MARKINGS NOT STD 2406051907-2410312359
6/5/241906Z !STL 06/098 STL TWY D SHOULDER MARKINGS BTN TWY H AND TWY G NOT STD 2406051906-2410312359
6/5/241904Z !STL 06/097 STL TWY G SHOULDER MARKINGS BTN APCH END RWY 30L AND TXL C EAST SIDE NOT STD 2406051904-2410312359
6/5/241856Z !STL 06/096 STL TWY D EDGE MARKINGS BTN TWY H AND TWY G NOT STD 2406051856-2410312359
6/5/241856Z !STL 06/095 STL TWY D HLDG PSN MARKINGS FOR ILS BTN TWY H AND TWY G NOT STD 2406051856-2410312359
6/5/241855Z !STL 06/094 STL APRON TXL C EDGE MARKINGS NOT STD 2406051855-2410312359
6/5/241855Z !STL 06/093 STL TWY G EDGE MARKINGS BTN APCH END RWY 30L AND TXL C EAST SIDE NOT STD 2406051855-2410312359
6/5/241825Z !STL 06/091 STL APRON TXL C BTN TWY C5 AND TWY D3 CLSD TO ACFT WINGSPAN MORE THAN 118FT 2406051825-2409302359
6/4/242023Z !STL 06/064 STL TWY D3 BTN TWY D AND TXL C CLSD 2406042023-2409302359
6/4/242023Z !STL 06/063 STL TWY J BTN RWY 12R/30L AND TWY D CLSD 2406042023-2409302359
6/4/242023Z !STL 06/062 STL TWY L BTN RWY 12R/30L AND TWY D CLSD 2406042023-2409302359
6/4/242023Z !STL 06/061 STL TWY M BTN RWY 12R/30L AND TWY D CLSD 2406042023-2409302359
6/4/242023Z !STL 06/060 STL TWY C4 BTN TWY D AND TXL C CLSD 2406042023-2409302359
6/4/242023Z !STL 06/059 STL TWY D4 BTN TWY D AND TXL C CLSD 2406042023-2409302359
6/4/242023Z !STL 06/058 STL APRON TXL C BTN TWY D4 AND TXL D1 CLSD 2406042023-2409302359
6/4/242022Z !STL 06/057 STL TWY D BTN TWY C6 AND TWY D1 CLSD 2406042022-2409302359
6/4/242022Z !STL 06/056 STL TWY C5 BTN TWY D AND TXL C CLSD 2406042022-2409302359
6/4/241600Z !STL 06/051 STL TWY C5 EDGE MARKINGS BTN TWY D AND TXL C EAST SIDE NOT STD 2406041600-2407312359
5/30/241737Z !STL 05/625 STL TWY A3 CL MARKINGS BTN RWY 11/29 AND TWY B SOUTH SIDE NOT STD 2405301737-2406142359
5/22/242300Z !STL 05/435 STL AIRSPACE UAS WI AN AREA DEFINED AS 0.3NM RADIUS OF
383259.80N0902130.30W (9.6NM W CPS) SFC-400FT AGL
2405222300-2409021700
5/14/241427Z !STL 05/285 STL NAV ILS RWY 12L CAT II NA 2405141427-2407312000EST
5/3/241557Z !STL 05/072 STL NAV ILS RWY 06 GP U/S 2405031557-2406122000EST
4/24/241650Z !STL 04/475 STL TWY V CL MARKINGS BTN RWY 12R/30L AND TWY V2 NOT STD 2404241650-2408312359
4/24/241313Z !STL 04/468 STL TWY F CL MARKINGS BTN TWY F6 AND TWY K NOT STD 2404241313-2408312359
4/22/241354Z !STL 04/424 STL TWY L EDGE MARKINGS BTN TXL F7 AND TWY F WEST SIDE NOT STD 2404221354-2408312359
4/22/241352Z !STL 04/423 STL TWY F EDGE MARKINGS BTN TWY F7 AND TWY L NORTH SIDE NOT STD 2404221352-2408312359
4/22/241350Z !STL 04/422 STL APRON TXL F7 EDGE MARKINGS NOT STD 2404221350-2408312359
4/17/240748Z !STL 04/326 STL NAV ILS RWY 12R U/S 2404170748-2407302000EST
4/16/241827Z !STL 04/318 STL RWY 30L ALS U/S 2404161827-2407312000
4/16/241826Z !STL 04/317 STL NAV ILS RWY 30L U/S 2404161826-2407312000
4/16/241825Z !STL 04/316 STL RWY 30L PAPI U/S 2404161825-2407312000
4/16/241824Z !STL 04/315 STL RWY 12R ALS U/S 2404161824-2407312000
4/16/241823Z !STL 04/314 STL RWY 12R PAPI U/S 2404161823-2407312000
4/16/241822Z !STL 04/313 STL NAV ILS RWY 12R U/S 2404161822-2407312000
4/9/241449Z !STL 04/202 STL TWY V EDGE MARKINGS BTN APCH END RWY 24 AND TWY F NOT STD 2404091449-2407312359
4/9/241436Z !STL 04/201 STL TWY N EDGE MARKINGS BTN APCH END RWY 24 AND TWY N RUNUP PAD NOT STD 2404091436-2407312359
4/7/241404Z !STL 04/158 STL TWY S EDGE MARKINGS BTN APCH END RWY 06 AND RWY 12R/30L NOT STD 2404071404-2407312359
3/19/242215Z !STL 03/351 STL TWY L CL MARKINGS BTN RWY 12L/30R AND TWY E NOT STD 2403192215-2407312359
3/18/241404Z !STL 03/326 STL TWY T CL MARKINGS BTN APCH END RWY 29 AND TWY C NOT STD 2403181404-2407312359
3/17/241340Z !STL 03/311 STL APRON TXL C NONMOVEMENT AREA BDRY MARKINGS W SIDE NOT STD 2403171340-2407312359
3/12/242154Z !STL 03/206 STL TWY C BTN APCH END RWY 12R AND TWY V CLSD 2403122154-2407312359
3/4/241530Z !STL 03/061 STL TWY S1 CL MARKINGS NOT STD 2403041530-2407312359
2/29/240114Z !STL 02/506 STL RWY 12R/30L EDGE MARKINGS NOT STD 2402290114-2411302359
2/29/240113Z !STL 02/505 STL RWY 06/24 EDGE MARKINGS NW SIDE NOT STD 2402290113-2411302359
2/29/240113Z !STL 02/504 STL TWY E2 CL MARKINGS NOT STD 2402290113-2411302359
2/29/240112Z !STL 02/501 STL TWY D BTN TWY C AND TWY V CLSD 2402290112-2407312359
2/4/241503Z !STL 02/034 STL TWY S1 SFC PAINTED HLDG PSN SIGNS NOT STD 2402041503-2407312359
2/4/241451Z !STL 02/033 STL TWY C CL MARKINGS BTN RWY 06/24 AND CHARLIE PAD NOT STD 2402041451-2407312359
2/4/241424Z !STL 02/031 STL TWY D1 CL MARKINGS NOT STD 2402041424-2407312359
FDC
6/4/241734Z !FDC 4/3223 STL SID ST LOUIS LAMBERT INTL, ST LOUIS, MO.
LINDBERGH EIGHT DEPARTURE...
TAKEOFF MINIMUMS: RWY 24, 300-1 1/8 OR STANDARD WITH MINIMUM CLIMB OF 205 FT/NM TO 800, OR ALTERNATIVELY, WITH STANDARD TAKEOFF MINIMUMS AND A NORMAL 200 FT/NM CLIMB GRADIENT, TAKEOFF MUST OCCUR NO LATER THAN 1100 FEET PRIOR TO DER.
TAKEOFF MINIMUMS: RWY 30L, 300-1 OR STANDARD WITH MINIMUM CLIMB OF 250 FT/NM TO 800.
ALL OTHER DATA REMAINS AS PUBLISHED. 2406041734-2606041734EST
6/4/241733Z !FDC 4/3222 STL PART 1 OF 4 ODP ST LOUIS LAMBERT INTL,
ST LOUIS, MO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3...
TAKEOFF MINIMUMS: RWY 24, 300-1 1/8 OR STANDARD WITH MINIMUM CLIMB
OF 205 FT/NM TO 800, OR ALTERNATIVELY, WITH STANDARD TAKEOFF
MINIMUMS AND A NORMAL 200 FT/NM CLIMB GRADIENT, TAKEOFF MUST OCCUR
NO LATER THAN 1100 FEET PRIOR TO DER. TAKEOFF OBSTACLE NOTES: RWY
24: TREE 1151 FT FROM DER, 707 FT LEFT OF CENTERLINE, 591 FT MSL.
TREE 1806 FT FROM DER, 591 FT RIGHT OF CENTERLINE, 616 FT MSL.
TREES BEGINNING 1886 FT FROM DER, 563 FT RIGHT OF CENTERLINE, UP TO
622 FT MSL. TREE 2100 FT FROM DER, 493 FT RIGHT OF CENTERLINE, 630
FT MSL. TREES BEGINNING 2190 FT FROM DER, 620 FT RIGHT OF
CENTERLINE, UP TO 643 FT MSL. TREES BEGINNING 2595 FT FROM DER, 189
FT LEFT OF CENTERLINE, UP TO 642 FT MSL. TREES BEGINNING 2756 FT
FROM DER, 108 FT LEFT OF CENTERLINE, UP TO 645 FT MSL. TREES
BEGINNING 2861 FT FROM DER, 54 FT LEFT OF CENTERLINE, UP TO 648 FT
MSL. TREES BEGINNING 3015 FT FROM DER, 138 FT LEFT OF CENTERLINE,
UP TO 658 FT MSL. TREES BEGINNING 3034 FT FROM DER, 15 FT RIGHT OF
CENTERLINE, UP TO 650 FT MSL. TREES BEGINNING 3068 FT FROM DER, 17
FT LEFT OF CENTERLINE, UP TO 659 FT MSL. TREES BEGINNING 3248 FT
FROM DER, 75 FT LEFT OF CENTERLINE, UP TO 661 FT MSL. TREES
BEGINNING 3354 FT FROM DER, 118 FT LEFT OF CENTERLINE, UP TO 663 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2406041733-2606041733EST
END PART 1 OF 4
!FDC 4/3222 STL PART 2 OF 4 ODP ST LOUIS LAMBERT INTL,
ST LOUIS, MO.
MSL. TREES BEGINNING 3472 FT FROM DER, 43 FT LEFT OF CENTERLINE, UP
TO 671 FT MSL. TREES BEGINNING 3568 FT FROM DER, 107 FT RIGHT OF
CENTERLINE, UP TO 653 FT MSL. TREE 3582 FT FROM DER, 4 FT RIGHT OF
CENTERLINE, 659 FT MSL. TREES BEGINNING 3593 FT FROM DER, 16 FT
RIGHT OF CENTERLINE, UP TO 660 FT MSL. TREES BEGINNING 3610 FT FROM
DER, 17 FT LEFT OF CENTERLINE, UP TO 673 FT MSL. TREES BEGINNING
3660 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO 674 FT MSL. TREES
BEGINNING 3722 FT FROM DER, 120 FT RIGHT OF CENTERLINE, UP TO 669
FT MSL. TREES BEGINNING 3912 FT FROM DER, 47 FT RIGHT OF
CENTERLINE, UP TO 679 FT MSL. TREES BEGINNING 4018 FT FROM DER, 3
FT RIGHT OF CENTERLINE, UP TO 684 FT MSL. TREE 4671 FT FROM DER, 16
FT LEFT OF CENTERLINE, 676 FT MSL. BUILDING 5165 FT FROM DER, 504
FT RIGHT OF CENTERLINE, 90 FT AGL/696 FT MSL. TOWERS BEGINNING 1.1
NM FROM DER, 2068 FT RIGHT OF CENTERLINE, UPTO 106 FT AGL/723 FT
MSL.
TAKEOFF MINIMUMS: RWY 30L, 300-1 OR STANDARD WITH MINIMUM CLIMBOF
250 FT/NM TO 800.
TAKEOFF OBSTACLES NOTES: RWY 30L: TERRAIN 40 FT FROM DER, 276 FT
RIGHT OF CENTERLINE,545 FT MSL. TERRAIN 193 FT FROM DER, 270 FT
RIGHT OF CENTERLINE, 547 FT MSL. TRAVERSE WAY, TERRAIN,NAVAID,
ALL OTHER DATA REMAINS AS PUBLISHED. 2406041733-2606041733EST
END PART 2 OF 4
!FDC 4/3222 STL PART 3 OF 4 ODP ST LOUIS LAMBERT INTL,
ST LOUIS, MO.
BUILDING, FENCE BEGINNING 282 FT FROM DER, ON CENTERLINE, UP TO 571
FT MSL. TRAVERSE WAY,LIGHT POLES BEGINNING 836 FT FROM DER, 217 FT
RIGHT OF CENTERLINE, UP TO 580 FT MSL. TRAVERSE WAY906 FT FROM DER,
600 FT LEFT OF CENTERLINE, 569 FT MSL. TERRAIN, ELECTRICAL SYSTEM
BEGINNING 1374 FTFROM DER, 672 FT RIGHT OF CENTERLINE, UP TO 592 FT
MSL. POLE 1685 FT FROM DER, 640 FT LEFT OFCENTERLINE, 39 FT AGL/585
FT MSL. TREES BEGINNING 2184 FT FROM DER, 820 FT RIGHT OF
CENTERLINE, UPTO 653 FT MSL. TREES BEGINNING 2465 FT FROM DER, 863
FT RIGHT OF CENTERLINE, UP TO 657 FT MSL. TREE,POLE, BUILDING
BEGINNING 2669 FT FROM DER, 604 FT RIGHT OF CENTERLINE, UP TO 661
FT MSL. TREE 3506 FTFROM DER, 818 FT LEFT OF CENTERLINE, 663 FT
MSL. TREE, BUILDING BEGINNING 3665 FT FROM DER, 761 FTRIGHT OF
CENTERLINE, UP TO 665 FT MSL. TREE, POLE BEGINNING 4157 FT FROM
DER, 280 FT RIGHT OFCENTERLINE, UP TO 682 FT MSL. TREE 5154 FT FROM
DER, 523 FT LEFT OF CENTERLINE, 678 FT MSL. TREE 5160FT FROM DER,
292 FT LEFT OF CENTERLINE, 686 FT MSL. TREES BEGINNING 5175 FT FROM
DER, 386 FT LEFT OFCENTERLINE, UP TO 697 FT MSL. TREES BEGINNING
5288 FT FROM DER, 199 FT LEFT OF CENTERLINE, UP TO 703FT MSL. TREES
BEGINNING 5396 FT FROM DER, 400 FT LEFT OF CENTERLINE, UP TO 704 FT
MSL. TREE, ANTENNABEGINNING 5490 FT FROM DER, 690 FT LEFT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2406041733-2606041733EST
END PART 3 OF 4
!FDC 4/3222 STL PART 4 OF 4 ODP ST LOUIS LAMBERT INTL,
ST LOUIS, MO.
CENTERLINE, UP TO 709 FT MSL. TREE 1 NM FROM DER, 1204 FTLEFT OF
CENTERLINE, 706 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2406041733-2606041733EST
END PART 4 OF 4
2/1/241323Z !FDC 4/0254 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (GPS) RWY 6, AMDT 2...
LNAV/VNAV DA NA ALL CATS.
NOTE: RWY 6 HELICOPTER VISIBILITY REDUCTION BELOW RVR 4000 NOT AUTHORIZED.
2402011323-2602011323EST
1/11/241755Z !FDC 4/2936 STL SID ST LOUIS LAMBERT INTL, ST LOUIS, MO.
PLESS FIVE DEPARTURE...
NASHVILLE TRANSITION NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
BNA VOR OUT OF SERVICE. 2401111755-2408221755EST
9/1/231613Z !FDC 3/4825 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (GPS) Y RWY 12R, AMDT 1D...
LNAV MDA 1020/HAT 480.
2309011613-2509011613EST
7/11/231438Z !FDC 3/4218 STL ODP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3...
TAKE-OFF MINIMUMS RWY 24: 300-1 3/8 OR STANDARD WITH MINIMUM CLIMB OF 205 FT PER NM TO 800.
ALL OTHER DATA REMAINS AS PUBLISHED. 2307111438-2507111438EST
7/5/231202Z !FDC 3/1145 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (RNP) Z RWY 30L, AMDT 1A...
RNP 0.15 DA 987/HAT 404 ALL CATS; RNP 0.30 DA 1042/HAT 459 ALL CATS.
2307051202-2507051202EST
7/5/231202Z !FDC 3/1141 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (GPS) Y RWY 30R, AMDT 2A...
LNAV/VNAV DA 914/HAT 309 ALL CATS; LNAV MDA 1020/HAT 415 ALL CATS.
2307051202-2507051202EST
7/5/231154Z !FDC 3/1136 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (RNP) Z RWY 11, ORIG-B...
RNP 0.30 DA 917/HAT 299 ALL CATS, VISIBILITY ALL CATS 3/4.
2307051154-2507051154EST
6/29/230201Z !FDC 3/8509 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
ILS RWY 11 (CAT II - III), AMDT 1 ...
ILS RWY 12L (CAT II - III), AMDT 6C ...
ILS RWY 30R (CAT II - III), AMDT 12 ...
PROCEDURE NA EXC FOR RDO ALTIMETER TOLERANT ACFT AND ACFT USING APPROVED ALTERNATIVE METHODS OF COMPLIANCE DUE TO 5G C-BAND INTERFERENCE PLUS SEE AIRWORTHINESS DIRECTIVE 2023-10-02 AND 5G C-BAND DOMESTIC NOTICES. 2306290201-2506290155EST
6/21/231320Z !FDC 3/4117 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (RNP) Z RWY 12R, ORIG-C...
RNP 0.30 DA 1029/HAT 489 ALL CATS.
2306211320-2506211320EST
6/21/231320Z !FDC 3/4116 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (GPS) Y RWY 30L, AMDT 2...
LNAV/VNAV VIS ALL CATS RVR 4000.
LNAV VIS CATS A/B RVR 4000.
CHANGE NOTE TO READ: FOR INOP ALS, INCREASE LPV CAT E VISIBILITY TO RVR 4000, LNAV/VNAV ALL CATS VISIBILITY TO RVR 6000, LNAV CATS A/B VISIBILITY TO RVR 5500, AND LNAV CATS C/D/E VISIBILITY TO 1 3/8 SM.
RWY 30L HELICOPTER VISIBILITY REDUCTION BELOW RVR 4000 NOT AUTHORIZED.
2306211320-2506211320EST
6/21/231320Z !FDC 3/4115 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
ILS OR LOC RWY 6, AMDT 3...
S-ILS 6 DA NA ALL CATS.
CHANGE NOTE TO READ: FOR INOP ALS, INCREASE S-LOC 6 CATS A/B VISIBILITY TO RVR 5000 AND CATS C/D/E VISIBILITY TO 1 3/8 SM.
RWY 6 HELICOPTER VISIBILITY REDUCTION BELOW RVR 4000 NOT AUTHORIZED.
2306211320-2506211320EST
6/21/231320Z !FDC 3/4114 STL IAP U.S. DOD ST LOUIS LAMBERT INTL, ST LOUIS, MO.
TACAN RWY 30L, AMDT 1...
RWY 30L HELICOPTER VISIBILITY REDUCTION BELOW RVR 5000 NOT AUTHORIZED.
DISREGARD ALTERNATE MINIMUMS NA ICON.
ALTERNATE MINIMUMS: STANDARD.
2306211320-2506211320EST
6/21/231320Z !FDC 3/4112 STL IAP U.S. DOD ST LOUIS LAMBERT INTL, ST LOUIS, MO.
TACAN RWY 12R, AMDT 1...
CHANGE NOTE TO READ: RWY 12R HELICOPTER VISIBILITY REDUCTION BELOW RVR 5000 NOT AUTHORIZED.
DISREGARD ALTERNATE MINIMUMS NA ICON.
ALTERNATE MINIMUMS: STANDARD.
2306211320-2506211320EST
6/7/231750Z !FDC 3/7240 STL SID ST LOUIS LAMBERT INTL, ST LOUIS, MO.
ROTRY FIVE DEPARTURE (RNAV)...
BRADFORD TRANSITION: ROTRY TO SKUTR MOCA 2300. SKUTR TO BDF VORTAC MOCA 2500. ALL OTHER DATA REMAINS AS PUBLISHED. 2306071750-2506301750EST
2/27/231729Z !FDC 3/0159 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (RNP) Z RWY 12L, ORIG-C...
RNP 0.30 DA 1055/HAT 514 ALL CATS.
2302271729-2502271729EST
11/22/222021Z !FDC 2/5994 STL IAP ST LOUIS LAMBERT INTL, ST LOUIS, MO.
RNAV (GPS) RWY 24, AMDT 1C...
LNAV/VNAV DA 1015/481 ALL CATS, VIS 1 1/8 ALL CATS.
2211222021-2411222021EST
Yes
ALL
CITY OF ST LOUIS
1200 MARKET STREET
ST LOUIS, MO 63103
Phone: 314-622-4800
MS. RHONDA HAMM-NIEBRUEGGE
BOX 10212
ST LOUIS, MO 63145
Phone: 314-426-8000
SAINT LOUIS FSS (STL)
Toll Free: 1-800-WX-BRIEF
STL
--
--
N/A
Yes - Lighted
No
Yes
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
3
20
0
0
0
Major
Major
High & Low Pressure
High & Low Pressure
Air Freight
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 06/24

7603 ft. x 150 ft.
CONC
Fair
GRVD
HIGH
85 /R/B/W/T
75,000lbs
176,000lbs
280,000lbs
660,000lbs
  Runway 06 Runway 24
True Heading 63°243°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 38° 44' 48"N 38° 45' 22"N
Longitude 90° 22' 52"W 90° 21' 27"W
Elevation 551' 533'
Threshold Crossing Height 51 ft. AGL 53 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights MALSR MALS
Centerline Lights
Runway End Identifier Lights

Runway 11/29

9000 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH
85 /R/B/W/T
75,000lbs
200,000lbs
325,000lbs
700,000lbs
  Runway 11 Runway 29
True Heading 122°302°
Traffic Pattern Right
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 38° 45' 36"N 38° 44' 48"N
Longitude 90° 24' 36"W 90° 22' 59"W
Elevation 617' 555'
Threshold Crossing Height 67 ft. AGL 73 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights ALSF2 ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 12L/30R

9013 ft. x 150 ft.
CONC
Good
GRVD
HIGH
85 /R/B/W/T
75,000lbs
200,000lbs
350,000lbs
760,000lbs
  Runway 12L Runway 30R
True Heading 122°302°
Traffic Pattern Right
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 38° 45' 06"N 38° 44' 19"N
Longitude 90° 21' 59"W 90° 20' 23"W
Elevation 528' 604'
Threshold Crossing Height 56 ft. AGL 55 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4R
Approach Lights ALSF2 ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights No

Runway 12R/30L

11020 ft. x 150 ft.
CONC
Good
GRVD
HIGH
85 /R/B/W/T
75,000lbs
200,000lbs
350,000lbs
760,000lbs
  Runway 12R Runway 30L
True Heading 122°302°
Traffic Pattern Right Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 38° 45' 14"N 38° 44' 16"N
Longitude 90° 22' 45"W 90° 20' 47"W
Elevation 541' 585'
Threshold Crossing Height 54 ft. AGL 58 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No
A110-10WAIVER TO CONDUCT SIMUL APCHS TO PARL RYS SEPARATED BY 1,300 FT IN EFCT.
A110-15WG TIP CLNC WITH GND VEH NOT ADQT ALG N SIDE OF MAIN TRML APN.
A110-33ASDE-X IN USE. OPER TRANSPONDERS WITH ALT REPORTING MODE AND ADS-B (IF EQUIPPED) ENABLED ON ALL ARPT SURFACES.
A110-37A-GEAR: A-G ARE KEPT IN RECESSED POSN TIL REQ FOR USE. TWR MUST BE NOTIFIED AT LEAST 5 SEC PRIOR TO ENGAGEMENT SO THAT CABLE MAY BE RAISED.
A110-38TWY DELTA OR TAXILANE CHARLIE FM TWY SIERRA TO TWY GOLF, B-747S ARE NOT AUTH TO PASS OR BE PASSED BY B767 OR OTR LRGR ACFT OPRG ON THE PARL TWY/TAXILANE.
A110-39TWY NOVEMBER BTN RWY 24 AND FOXTROT, RSTRD TO ACFT WITH A WINGSPAN OF LESS THAN 79 FT (CRJ-900 OR SMLR) WHEN ACFT ARE PARKED ON THE NOVEMBER PAD. THIS AREA IS RSTRD TO ALL OPNS WHEN ACFT ARE PERFORMING END RUN-UPS IN THE NOVEMBER PAD.
A110-40TWY VICTOR, UNDERLYING THE RWY 12L FNA CRS, IS RSTRD TO ACFT WITH A TAIL HGT OF 25 FT OR LESS (CRJ-700 OR SMLR) WHEN ACFT ARE LNDG ON RWY 12L.
A110-42TWY CHARLIE, EAST OF TWY DELTA ONE TO THE AER 30L, RSTRD TO B-737 OR SMLR ACFT (WINGSPAN LESS THAN 118 FT) WHEN ACFT ARE PARKED ON THE HOTEL PAD.
A110-45TWY CHARLIE, FROM TWY CHARLIE SIX TO TWY DELTA FOUR, RSTRD TO B757-300 SERIES OR SMLR WHEN PASSING BHND ACFT THAT HAVE MADE THE INITIAL 10 FT PUSHBACK.
A110-46TWY ALPHA EAST OF TWY TANGO, TWY SIERRA AND RWY 6/24 SOUTH OF TWY BRAVO, NO ACFT OR VEHICLE OPNS WHEN ARRIVING OR DEPG RWY 11 OR ARRIVING RWY 29.
A110-47TWY LIMA, NORTH OF RWY 12L/30R, ACFT LRGR THAN A GULFSTREAM VI TAX NBND ARE PROHIBITED FM MAKING A RIGHT TURN EBND ON TWY FOXTROT.
A110-48TWY VICTOR 2 IS UNAVBL TO B-767 OR LRGR ACFT (WINGSPAN 118 FT OR GTR).
A110-49TWY VICTOR 2, B-737 (WINGSPAN GTR THAN 79 FT BUT LESS THAN 118 FT) MUST PERFORM JUDGMENTAL OVERSTEERING INSTEAD OF COCKPIT OVR CNTRLN STEERING WHEN TAX.
A110-50TWY KILO 1 IS UNAVBL TO B-767 OR LRGR ACFT (WINGSPAN 118 FT OR GTR).
A110-51TWY ECHO, BTN TWY NOVEMBER AND TWY LIMA RSTRD TO B-767 OR SMLR ACFT (WINGSPAN LESS THAN 171 FT) WHEN ACFT ARE PARKED ON THE ECHO PAD.
A110-52TWY CHARLIE, FM TWY SIERRA TO TWY CHARLIE SEVEN, RSTRD TO B-767 OR SMLR ACFT (156 FT AVBL) WHEN ACFT ARE PARKED IN THE CHARLIE PAD. RSTRN IS FOR TAX ACFT, LRGR ACFT MAY BE TOWED THRU AREA.
A110-53TWY CHARLIE, FROM TWY CHARLIE SEVEN TO TWY CHARLIE SIX, RSTRD TO A B757-300 SERIES OR SMLR.
ST LOUIS LAMBERT INTL (ICAO: KSTL, IATA: STL) is a public airport located in ST LOUIS, MO.
