9/28/231759Z
|
!FDC 3/7110 TDO PART 1 OF 3 ODP ED CARLSON MEML FLD - SOUTH LEWIS
COUNTY, TOLEDO, WA.
ATASY TWO DEPARTURE (RNAV) ...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 6: WIND INDICATOR, TOWER, FENCE, TREE BEGINNING 7 FT FROM
DER, 158 FT LEFT OF CENTERLINE, UP TO 20 FT AGL/390 FT MSL.
TREES BEGINNING 17 FT FROM DER, 257 FT RIGHT OF CENTERLINE, UP TO
20 FT AGL/393 FT MSL.
TREES BEGINNING 189 FT FROM DER, 16 FT RIGHT OF CENTERLINE, UP TO
396 FT MSL.
TREE 601 FT FROM DER, 277 FT RIGHT OF CENTERLINE, 29 FT AGL/400 FT
MSL.
TREE 814 FT FROM DER, 378 FT RIGHT OF CENTERLINE, 32 FT AGL/404 FT
MSL.
TREE 1569 FT FROM DER, 903 FT LEFT OF CENTERLINE, 47 FT AGL/423 FT
MSL.
TERRAIN BEGINNING 5018 FT FROM DER, 1806 FT LEFT OF CENTERLINE, UP
TO 601 FT MSL.
TERRAIN BEGINNING 5492 FT FROM DER, 1814 FT RIGHT OF CENTERLINE, UP
TO 538 FT MSL.
NOTE: RWY 24: TREE 16 FT FROM DER, 383 FT LEFT OF CENTERLINE, 39 FT
AGL/396 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309281759-2509281759EST
END PART 1 OF 3
!FDC 3/7110 TDO PART 2 OF 3 ODP ED CARLSON MEML FLD - SOUTH LEWIS
COUNTY, TOLEDO, WA.
POLE 63 FT FROM DER, 357 FT RIGHT OF CENTERLINE, 20 FT AGL/372 FT
MSL.
BUILDING BEGINNING 76 FT FROM DER, 407 FT RIGHT OF CENTERLINE, UP
TO 28 FT AGL/378 FT MSL.
TREE 106 FT FROM DER, 268 FT LEFT OF CENTERLINE, 48 FT AGL/402 FT
MSL.
POLE 224 FT FROM DER, 371 FT RIGHT OF CENTERLINE, 31 FT AGL/381 FT
MSL.
TREE 225 FT FROM DER, 404 FT RIGHT OF CENTERLINE, 384 FT MSL.
TREE 248 FT FROM DER, 379 FT RIGHT OF CENTERLINE, 386 FT MSL.
LIGHT POLES, TOWERS, TRAVERSE WAY, TREES BEGINNING 275 FT FROM DER,
135 FT RIGHT OF CENTERLINE, UP TO 80 FT AGL/435 FT MSL.
TREES, TRAVERSE WAY BEGINNING 335 FT FROM DER, 83 FT LEFT OF
CENTERLINE, UP TO 54 FT AGL/405 FT MSL.
TREES BEGINNING 2330 FT FROM DER, 191 FT RIGHT OF CENTERLINE, UP TO
102 FT AGL/445 FT MSL.
TREES BEGINNING 2419 FT FROM DER, 211 FT RIGHT OF CENTERLINE, UP TO
130 FT AGL/472 FT MSL.
TREES BEGINNING 2524 FT FROM DER, 35 FT RIGHT OF CENTERLINE, UP TO
138 FT AGL/481 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309281759-2509281759EST
END PART 2 OF 3
!FDC 3/7110 TDO PART 3 OF 3 ODP ED CARLSON MEML FLD - SOUTH LEWIS
COUNTY, TOLEDO, WA.
TREE 2719 FT FROM DER, 1090 FT LEFT OF CENTERLINE, 94 FT AGL/446 FT
MSL.
TREE 2840 FT FROM DER, 38 FT LEFT OF CENTERLINE, 108 FT AGL/453 FT
MSL.
TREES BEGINNING 2973 FT FROM DER, 31 FT RIGHT OF CENTERLINE, UP TO
482 FT MSL.
TERRAIN BEGINNING 5128 FT FROM DER, 1777 FT LEFT OF CENTERLINE, UP
TO 535 FT MSL.
TERRAIN BEGINNING 6003 FT FROM DER, 1902 FT RIGHT OF CENTERLINE, UP
TO 529 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309281759-2509281759EST
END PART 3 OF 3
|
