KVLA
VANDALIA MUNI
PublicPUB

3 miles NW of VANDALIA, IL
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 59' 29"N 89° 09' 58"W
537' MSL
1537' MSL
01W
JET A, 100LL
SAINT LOUIS (STL)
ST LOUIS
KANSAS CITY (ZKC)
11/28/24-12/26/24
KSLO (23nm) VFR
6:15 AM CST
Overcast 3,700'
10sm
40°F
25°F
30.21"Hg
180° 9kts
AO2 T00461037
KSLO 231215Z AUTO 18009KT 10SM OVC037 05/M04 A3021 RMK AO2 T00461037
Add Your Business

KVLA FBOs

Promote Listing
Vandalia Municipal Airport
UNICOM: 122.8
Phone: (618) 267-8035
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 12/17
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 4.50 3.75
Full Serve
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-AV

AWOS-AV
618-283-9595
 122.8

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KBLV (42nm)
Mon, 12/23 2:00 AM CST
Mon, 12/23 2:00 AM CST - Tue, 12/24 8:00 AM CST
VFR
2:00 AM CST - 8:00 AM CST
Scattered 15,000'
Few 5,000'
6sm
30.18"Hg
180° 9kts
Shear 190° 35kts @ 2000'
MVFR
Becoming 8:00 AM CST - 12:00 PM CST
Overcast 4,000'
Broken 3,000'
6sm
30.18"Hg
190° 12kts
Gusts 25kts
Shear 190° 35kts @ 2000'
MVFR
Becoming 12:00 PM CST - 6:00 PM CST
Overcast 3,500'
Broken 2,000'
Few 1,500'
6sm
30.15"Hg
190° 12kts
Gusts 20kts
Shear 190° 35kts @ 2000'
MVFR
Becoming 6:00 PM CST - 2:00 AM CST
Broken 1,500'
6sm
30.15"Hg
190° 6kts
MVFR
Becoming 2:00 AM CST - 8:00 AM CST
Overcast 1,000'
6sm
30.21"Hg
030° 6kts
TAF KBLV 230800Z 2308/2414 18009KT 9999 FEW050 SCT150 WS020/19035KT QNH3019INS
   BECMG 2314/2315 19012G25KT 9999 BKN030 OVC040 WS020/19035KT QNH3019INS
   BECMG 2318/2319 19012G20KT 9999 FEW015 BKN020 OVC035 WS020/19035KT QNH3014INS
   BECMG 2400/2401 19006KT 9999 BKN015 QNH3016INS
   BECMG 2408/2409 03006KT 9999 OVC010 QNH3021INS TX08/2322Z TN02/2308Z
KVLA
Domestic
12/13/241737Z !STL 12/215 VLA SVC AUTOMATED WX BCST SYSTEM VIS U/S 2412131737-2501312300
No
IRREGULAR
VANDALIA PARK DISTRICT
900 NORTH LOCUST
VANDALIA, IL 62471
Phone: 618-283-4973
CHAD FELDPOUCH
1754 N. 400 ST
VANDALIA, IL 62471
Phone: 618-267-8035
SAINT LOUIS FSS (STL)
Toll Free: 1-800-WX-BRIEF
STL
--
ACTVT REIL RWY 18, 27 & 36; PAPI RWY 18; MIRL RWY 09/27 - CTAF. MIRL RWY 18/36 PRESET TO LOW INTST, TO INCR INTST - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
None
Crop Dusting
Pilot Instruction

Runway 09/27

3001 ft. x 75 ft.
ASPH
Fair
NONE
MED

19,000lbs
--
--
--
  Runway 09 Runway 27
True Heading 90°270°
Traffic Pattern Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 38° 59' 25"N 38° 59' 25"N
Longitude 89° 10' 13"W 89° 09' 35"W
Elevation 532' 537'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes

Runway 18/36

3751 ft. x 100 ft.
ASPH
Good
PFC
MED

21,000lbs
--
--
--
  Runway 18 Runway 36
True Heading 180°360°
Traffic Pattern Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 59' 51"N 38° 59' 14"N
Longitude 89° 10' 02"W 89° 10' 02"W
Elevation 530' 533'
Threshold Crossing Height 20 ft. AGL --
Visual Glide Path Angle 3° --
Visual Slope Indicator P4L --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-1FOR WX ADVY, 3 CLICKS CTAF. PHONE (618)283-9595.
A110-2FOR CD CTC KANSAS CITY ARTCC AT 913-254-8508.
VANDALIA MUNI (ICAO: KVLA, IATA: VLA) is a public airport located in VANDALIA, IL.
