3/2/232141Z
|
!FDC 3/2323 XSA PART 1 OF 4 ODP TAPPAHANNOCK/ESSEX COUNTY,
TAPPAHANNOCK, VA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES:
NOTE: RWY 10, TREE 263 FT FROM DER, 564 FT RIGHT OF CENTERLINE, 145
FT MSL.
TREES BEGINNING 347 FT FROM DER, 500 FT LEFT OF CENTERLINE, UP TO
174 FT MSL.
TREE 405 FT FROM DER, 545 FT RIGHT OF CENTERLINE, 148 FT MSL.
TREE 535 FT FROM DER, 472 FT RIGHT OF CENTERLINE, 157 FT MSL.
TERRAIN BEGINNING 5649 FT FROM DER, 1972 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/342 FT MSL.
TERRAIN 1.2 NM FROM DER, 2438 FT LEFT OF CENTERLINE, 200 FT AGL/322
FT MSL.
TERRAIN 1.2 NM FROM DER, 2439 FT RIGHT OF CENTERLINE, 200 FT
AGL/328 FT MSL
NOTE: RWY 28, TREE 400 FT FROM DER, 514 FT LEFT OF CENTERLINE, 158
FT MSL.
TREES BEGINNING 535 FT FROM DER, 520 FT LEFT OF CENTERLINE, UP TO
175 FT MSL.
TREES BEGINNING 663 FT FROM DER, 108 FT LEFT OF CENTERLINE, UP TO
178 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303022141-2503022139EST
END PART 1 OF 4
!FDC 3/2323 XSA PART 2 OF 4 ODP TAPPAHANNOCK/ESSEX COUNTY,
TAPPAHANNOCK, VA.
TREE 1218 FT FROM DER, 11 FT RIGHT OF CENTERLINE, 169 FT MSL.
TREES BEGINNING 1391 FT FROM DER, 76 FT RIGHT OF CENTERLINE, UP TO
193 FT MSL.
TREES BEGINNING 1555 FT FROM DER, 159 FT RIGHT OF CENTERLINE, UP TO
220 FT MSL.
TREES BEGINNING 1577 FT FROM DER, 14 FT LEFT OF CENTERLINE, UP TO
183 FT MSL.
TREES BEGINNING 1665 FT FROM DER, 87 FT LEFT OF CENTERLINE, UP TO
205 FT MSL.
TREES BEGINNING 1893 FT FROM DER, 441 FT LEFT OF CENTERLINE, UP TO
206 FT MSL.
TREES BEGINNING 1976 FT FROM DER, 111 FT RIGHT OF CENTERLINE, UP TO
230 FT MSL.
TREES BEGINNING 2068 FT FROM DER, 797 FT LEFT OF CENTERLINE, UP TO
221 FT MSL.
TREES BEGINNING 2269 FT FROM DER, 229 FT LEFT OF CENTERLINE, UP TO
225 FT MSL.
TREES BEGINNING 2291 FT FROM DER, 35 FT LEFT OF CENTERLINE, UP TO
229 FT MSL.
TREE 2381 FT FROM DER, 342 FT RIGHT OF CENTERLINE, 239 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303022141-2503022139EST
END PART 2 OF 4
!FDC 3/2323 XSA PART 3 OF 4 ODP TAPPAHANNOCK/ESSEX COUNTY,
TAPPAHANNOCK, VA.
TREES BEGINNING 2385 FT FROM DER, 221 FT RIGHT OF CENTERLINE, UP TO
240 FT MSL.
TREES BEGINNING 2388 FT FROM DER, 186 FT LEFT OF CENTERLINE, UP TO
232 FT MSL.
TREE 2447 FT FROM DER, 48 FT RIGHT OF CENTERLINE, 241 FT MSL.
TREES BEGINNING 2452 FT FROM DER, 761 FT LEFT OF CENTERLINE, UP TO
233 FT MSL.
TREES BEGINNING 2495 FT FROM DER, 93 FT LEFT OF CENTERLINE, UP TO
238 FT MSL.
TREES BEGINNING 2526 FT FROM DER, 165 FT RIGHT OF CENTERLINE, UP TO
244 FT MSL.
TREES BEGINNING 2571 FT FROM DER, 61 FT RIGHT OF CENTERLINE, UP TO
246 FT MSL.
TREES BEGINNING 2612 FT FROM DER, 255 FT RIGHT OF CENTERLINE, UP TO
248 FT MSL.
TREES BEGINNING 2668 FT FROM DER, 20 FT LEFT OF CENTERLINE, UP TO
251 FT MSL.
TREES BEGINNING 2685 FT FROM DER, 48 FT RIGHT OF CENTERLINE, UP TO
250 FT MSL.
TREES BEGINNING 2703 FT FROM DER, 157 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2303022141-2503022139EST
END PART 3 OF 4
!FDC 3/2323 XSA PART 4 OF 4 ODP TAPPAHANNOCK/ESSEX COUNTY,
TAPPAHANNOCK, VA.
256 FT MSL.
TREES BEGINNING 2862 FT FROM DER, 61 FT LEFT OF CENTERLINE, UP TO
258 FT MSL.
TREES BEGINNING 2983 FT FROM DER, 25 FT RIGHT OF CENTERLINE, UP TO
258 FT MSL.
TREES BEGINNING 3220 FT FROM DER, 66 FT LEFT OF CENTERLINE, UP TO
262 FT MSL.
TERRAIN 4755 FT FROM DER, 1764 FT LEFT OF CENTERLINE, 200 FT
AGL/361 FT MSL.
TERRAIN 4995 FT FROM DER, 1746 FT LEFT OF CENTERLINE, 200 FT
AGL/365 FT MSL.
TERRAIN BEGINNING 5436 FT FROM DER, 1939 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/358 FT MSL.
TERRAIN BEGINNING 5738 FT FROM DER, 1956 FT LEFT OF CENTERLINE, UP
TO 200 FT AGL/368 FT MSL.
TERRAIN 1.4 NM FROM DER, 2802 FT RIGHT OF CENTERLINE, 200 FT
AGL/355 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303022141-2503022139EST
END PART 4 OF 4
|
