iFlightPlanner



...
COAL CREEK - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

L20
COAL CREEK
PublicPUB

1 miles W of YUKON CHARLEY RIVERS, AK
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
65° 18' 41"N 143° 08' 03"W
867' MSL
1867' MSL
30E
None Listed
FAIRBANKS (FAI)
DAWSON
ANCHORAGE (ZAN)
11/28/24-12/26/24
PAEG (59nm) IFR
2:53 AM AKST
Light Snow
Overcast 1,700'
1.25sm
4°F
-2°F
29.27"Hg
290° 4kts
AO2 SLP931 P0002 60002 70002 T11561189 11139 21156 50000 TSNO $
PAEG 231153Z AUTO 29004KT 1 1/4SM -SN OVC017 M16/M19 A2927 RMK AO2 SLP931 P0002 60002 70002 T11561189 11139 21156 50000 TSNO $
Add Your Business

L20 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

No TAF is available for this location.
L20
No NOTAM Available
No
UNATNDD
NPS YUKON-CHARLEY RIVERS NATL PRES
PO BOX 167
EAGLE, AK 99738
Phone: 907-547-2233
PARK SUPERINTENDENT
PO BOX 167
EAGLE, AK 99738
Phone: 907-455-0646
FAIRBANKS FSS (FAI)
Toll Free: 1-866-248-6516
FAI
--
--
N/A
Yes
No
No
None
No
0
0
0
0
0
0
None
None
None
None
None

Runway 01/19

3900 ft. x 80 ft.
GRAVEL
Poor
NONE


--
--
--
--
  Runway 01 Runway 19
True Heading 33°213°
Traffic Pattern
Markings
Markings Condition
Latitude 65° 18' 25"N 65° 18' 58"N
Longitude 143° 08' 28"W 143° 07' 38"W
Elevation 867' 855'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1RWY 01/19 NOT MAINTAINED DURING WINTER & EARLY SPRING.
A110-10LARGE ROCKS IN RAMP AND PARKING AREA , UP TO 18 INCHES.
A110-2RWY CONDITION NOT MONITORED. RECOMMEND VISUAL INSPECTION PRIOR TO USING.
A110-3RWY 01/19 IS A DREDGED CREEK BOTTOM SLOPING UPHILL NORTH TO SOUTH.
A110-48 FT HIGH DREDGE TAILINGS ON BOTH SIDES FULL LENGTH OF RWY 01/19.
A110-5RWY 01/19 SUBJECT TO ERRATIC WINDS.
A110-6WATCH FOR VEHICLES & PEDESTRIANS EAST EDGE OF RWY 01/19.
A110-7LIMITED ACFT PARKING ALONG WEST SIDE NEAR SOUTH END OF RWY 01/19.
A110-8SUAIS - 125.3/126.3 (1-800-758-8723).
A110-9RWY LOCATED IN VALLEY. RAPIDLY RISING TERRAIN TO THE WEST & EAST.
COAL CREEK (IATA: L20) is a public airport located in YUKON CHARLEY RIVERS, AK.
