iFlightPlanner



...
ALPINE COUNTY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

M45
ALPINE COUNTY
PublicPUB

3 miles N of MARKLEEVILLE, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 44' 05"N 119° 46' 01"W
5872' MSL
6672' MSL
16E
None Listed
RENO (RNO)
SAN FRANCISCO
OAKLAND (ZOA)
1/23/25-2/20/25
KTVL (15nm) VFR
11:53 PM PST
Clear
10sm
41°F
32°F
30.02"Hg
210° 8kts
Gusts 27kts
AO2 PK WND 18038/0659 SLP143 T00500000 400720022
KTVL 020753Z AUTO 21008G27KT 160V250 10SM CLR 05/00 A3002 RMK AO2 PK WND 18038/0659 SLP143 T00500000 400720022
Add Your Business

M45 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KTVL (15nm)
Sat, 2/1 10:23 PM PST
Sat, 2/1 10:00 PM PST - Sun, 2/2 10:00 PM PST
VFR
10:00 PM PST - 5:00 AM PST
Broken 3,500'
Scattered 2,000'
6sm
210° 20kts
Gusts 34kts
Shear 220° 55kts @ 2000'
MVFR
11:00 PM PST - 5:00 AM PST
Light Rain
Scattered 1,500'
5sm
Calm
MVFR
5:00 AM PST - 5:00 PM PST
Rain
Broken 3,500'
Scattered 1,500'
4sm
200° 20kts
Gusts 30kts
Shear 220° 55kts @ 2000'
VFR
5:00 PM PST - 10:00 PM PST
Broken 4,000'
Scattered 3,500'
6sm
200° 16kts
Gusts 26kts
Shear 220° 55kts @ 2000'
MVFR
5:00 PM PST - 10:00 PM PST
Light Rain
Broken 4,000'
Scattered 2,000'
4sm
Calm
KTVL 020623Z 0206/0306 21020G34KT P6SM SCT020 BKN035 WS020/22055KT
   PROB30 0207/0213 5SM -RA SCT015
   FM021300 20020G30KT 4SM RA SCT015 BKN035 WS020/22055KT
   FM030100 20016G26KT P6SM SCT035 BKN040 WS020/22055KT
   PROB30 0301/0306 4SM -RA SCT020 BKN040
M45
No NOTAM Available
No
UNATNDD
ALPINE COUNTY
50 DIAMOND VALLEY RD
MARKLEEVILLE, CA 96120
Phone: 530-694-2140
SAM BOOTH
50 DIAMOND VALLEY RD
MARKLEEVILLE, CA 96120
Phone: 530-694-2140
RENO FSS (RNO)
Toll Free: 1-800-WX-BRIEF
RNO
--
--
N/A
Yes
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 17/35

4443 ft. x 50 ft.
ASPH
Poor
NONE


--
--
--
--
  Runway 17 Runway 35
True Heading 184°4°
Traffic Pattern Right
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 38° 44' 27"N 38° 43' 43"N
Longitude 119° 45' 60"W 119° 46' 03"W
Elevation 5,827' 5,872'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1LARGE STONES ALONG EDGE OF RWY OFF GRADED SFC.
A110-2NO SNOW REMOVAL, ARPT CLOSED WHEN SNOW ON RUNWAY.
A110-3TREES PENETRATING TRANSITIONAL SFCS E & W OF RY.
A110-4SOIL CONDITIONS OFF RY IS POOR IN WET CONDITIONS. CALL PUBLIC WORKS FOR ADDITIONAL INFORMATION 530-694-2140 EXT."0".
A110-5RY 17/35 LIMITED BY AIRPORT OPERATOR TO 4,800 LBS SINGLE WHEEL, 9,600 LBS DUAL WHEEL.
A110-6FOR CD CTC OAKLAND ARTCC AT 510-745-3380.
ALPINE COUNTY (IATA: M45) is a public airport located in MARKLEEVILLE, CA.
