| Domestic |
|
12/17/241620Z
|
!IPT 12/174 N94 OBST TOWER LGT (ASR 1027269) 402040.00N0770945.00W (9.5NM NE N94) 930.1FT (395.0FT AGL) U/S 2412171620-2412232359
|
| FDC |
|
6/1/231139Z
|
!FDC 3/4193 N94 PART 1 OF 2 ODP CARLISLE, CARLISLE, PA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 10, POLE BEGINNING 10 FT FROM DER, 9 FT
RIGHT OF CENTERLINE, UP TO 2 FT AGL/512 FT MSL. POLE BEGINNING 10
FT FROM DER, 10 FT LEFT OF CENTERLINE, UP TO 2 FT AGL/511 FT MSL.
TERRAIN 13 FT FROM DER, 190 FT RIGHT OF CENTERLINE, 519 FT MSL.
POLE 13 FT FROM DER, 139 FT RIGHT OF CENTERLINE, 5 FT AGL/521 FT
MSL. TERRAIN BEGINNING 1199 FT FROM DER, 137 FT LEFT OF CENTERLINE,
UP TO 551 FT MSL. TERRAIN BEGINNING 1336 FT FROM DER, 18 FT LEFT OF
CENTERLINE, UP TO 553 FT MSL. TERRAIN BEGINNING 1453 FT FROM DER,
16 FT LEFT OF CENTERLINE, UP TO 556 FT MSL. TERRAIN 1574 FT FROM
DER, 34 FT LEFT OF CENTERLINE, 557 FT MSL. TERRAIN BEGINNING 1580
FT FROM DER, 130 FT LEFT OF CENTERLINE, UP TO 561 FT MSL. TERRAIN
BEGINNING 1690 FT FROM DER, 46 FT LEFT OF CENTERLINE, UP TO 563 FT
MSL. TERRAIN BEGINNING 1780 FT FROM DER, 73 FT LEFT OF CENTERLINE,
UP TO 569 FT MSL. TREE, TERRAIN, BUILDING BEGINNING 1863 FT FROM
DER, 144 FT LEFT OF CENTERLINE, UP TO 43 FT AGL/591 FT MSL. TREE,
BUILDING, POLE BEGINNING 1986 FT FROM DER, 180 FT LEFT OF
CENTERLINE, UP TO 52 FT AGL/597 FT MSL. TREES BEGINNING 2268 FT
FROM DER, 113 FT RIGHT OF CENTERLINE, UP TO 86 FT AGL/613 FT MSL.
TREES BEGINNING 2294 FT FROM DER, 47 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011139-2506011139EST
END PART 1 OF 2
!FDC 3/4193 N94 PART 2 OF 2 ODP CARLISLE, CARLISLE, PA.
93 FT AGL/618 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306011139-2506011139EST
END PART 2 OF 2
|
