| Domestic |
|
5/31/241243Z
|
!RIU 05/194 O27 RWY 28 PAPI U/S 2405311243-2412092111EST
|
|
12/19/231949Z
|
!RIU 12/108 O27 OBST TOWER LGT (ASR 1015784) 373755.00N1204507.00W (7.9NM SSE O27) 446.5FT (271.7FT AGL) U/S 2312191949-2406012359
|
| FDC |
|
5/15/242148Z
|
!FDC 4/4657 O27 IAP OAKDALE, OAKDALE, CA.
VOR-A, AMDT 1...
PROCEDURE NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
LIN VOR OUT OF SERVICE. 2405152148-2406142148EST
|
|
2/15/231424Z
|
!FDC 3/6229 O27 PART 1 OF 2 ODP OAKDALE, OAKDALE, CA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 10, SIGN, LIGHT POLES BEGINNING 28 FT
FROM DER, 75 FT LEFT OF CENTERLINE, UP TO 6 FT AGL/239 FT MSL.
LIGHT POLES 31 FT FROM DER, 77 FT RIGHT OF CENTERLINE, 4 FT AGL/239
FT MSL.
TREE 468 FT FROM DER, 376 FT LEFT OF CENTERLINE, 260 FT MSL.
TREE 578 FT FROM DER, 594 FT RIGHT OF CENTERLINE, 255 FT MSL.
TERRAIN, TREE BEGINNING 653 FT FROM DER, 35 FT RIGHT OF CENTERLINE,
UP TO 258 FT MSL.
TERRAIN 752 FT FROM DER, 311 FT RIGHT OF CENTERLINE, 263 FT MSL.
TERRAIN 782 FT FROM DER, 323 FT RIGHT OF CENTERLINE, 266 FT MSL.
TREE, TERRAIN BEGINNING 792 FT FROM DER, 310 FT RIGHT OF
CENTERLINE, UP TO 269 FT MSL.
TREE, TERRAIN, VEGETATION BEGINNING 912 FT FROM DER, 201 FT RIGHT
OF CENTERLINE, UP TO 274 FT MSL.
TREES BEGINNING 1327 FT FROM DER, 677 FT RIGHT OF CENTERLINE, UP TO
275 FT MSL.
POLE 1542 FT FROM DER, 636 FT RIGHT OF CENTERLINE, 39 FT AGL/305 FT
MSL.
POLE 1544 FT FROM DER, 538 FT RIGHT OF CENTERLINE, 53 FT AGL/320 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2302151424-2502151402EST
END PART 1 OF 2
!FDC 3/6229 O27 PART 2 OF 2 ODP OAKDALE, OAKDALE, CA.
MSL.
RWY 28, LIGHT POLES 29 FT FROM DER, 77 FT RIGHT OF CENTERLINE, 4 FT
AGL/226 FT MSL.
LIGHT POLES 31 FT FROM DER, 75 FT LEFT OF CENTERLINE, 3 FT AGL/226
FT MSL.
TREE 646 FT FROM DER, 488 FT RIGHT OF CENTERLINE, 255 FT MSL.
TREE 1207 FT FROM DER, 403 FT LEFT OF CENTERLINE, 261 FT MSL.
TRANSMISSION LINE 3273 FT FROM DER, 952 FT LEFT OF CENTERLINE, 129
FT AGL/327 FT MSL.
TRANSMISSION LINE 3886 FT FROM DER, 477 FT LEFT OF CENTERLINE, 133
FT AGL/329 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2302151424-2502151402EST
END PART 2 OF 2
|
