4/4/231758Z
|
!FDC 3/6045 W41 PART 1 OF 3 ODP CRISFIELD-SOMERSET COUNTY,
CRISFIELD, MD.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG-A...
TAKEOFF OBSTACLE NOTES: RWY 14: TREE 188 FT FROM DER, 410 FT RIGHT
OF CENTERLINE, 22 FT MSL.
TREE 321 FT FROM DER, 241 FT LEFT OF CENTERLINE, 18 FT MSL.
BUILDINGS, POLE BEGINNING 323 FT FROM DER, 77 FT RIGHT OF
CENTERLINE, UP TO 25 FT MSL.
TREES, POLES, TRAVERSE WAY BEGINNING 368 FT FROM DER, 74 FT LEFT OF
CENTERLINE, UP TO 47 FT MSL.
POLE, TREE BEGINNING 495 FT FROM DER, 408 FT RIGHT OF CENTERLINE,
UP TO 37 FT MSL.
TREES BEGINNING 598 FT FROM DER, 472 FT RIGHT OF CENTERLINE, UP TO
39 FT MSL.
TREES BEGINNING 685 FT FROM DER, 299 FT RIGHT OF CENTERLINE, UP TO
48 FT MSL.
TREES BEGINNING 792 FT FROM DER, 291 FT RIGHT OF CENTERLINE, UP TO
51 FT MSL.
TREES BEGINNING 956 FT FROM DER, 457 FT RIGHT OF CENTERLINE, UP TO
62 FT MSL.
TREES BEGINNING 1200 FT FROM DER, 227 FT RIGHT OF CENTERLINE, UP TO
83 FT MSL.
86 FT MSL. 2304041758-2504041758EST
END PART 1 OF 3
!FDC 3/6045 W41 PART 2 OF 3 ODP CRISFIELD-SOMERSET COUNTY,
CRISFIELD, MD.
TREES BEGINNING 1402 FT FROM DER, 75 FT RIGHT OF CENTERLINE, UP TO
86 FT MSL.
TREE 1506 FT FROM DER, 492 FT RIGHT OF CENTERLINE, 88 FT MSL.
TREE 1526 FT FROM DER, 692 FT RIGHT OF CENTERLINE, 98 FT MSL.
TREES BEGINNING 1545 FT FROM DER, 184 FT RIGHT OF CENTERLINE, UP TO
99 FT MSL.
TREES BEGINNING 1624 FT FROM DER, 29 FT RIGHT OF CENTERLINE, UP TO
113 FT MSL.
TREES BEGINNING 2062 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO
101 FT MSL.
TREE 3475 FT FROM DER, 544 FT LEFT OF CENTERLINE, 106 FT MSL.
TREES BEGINNING 3578 FT FROM DER, 618 FT LEFT OF CENTERLINE, UP TO
107 FT MSL. RWY 32: TREES BEGINNING 78 FT FROM DER, 499 FT RIGHT
OF CENTERLINE, UP TO 60 FT MSL.
TREE 295 FT FROM DER, 493 FT RIGHT OF CENTERLINE, 65 FT MSL.
TREE 391 FT FROM DER, 557 FT RIGHT OF CENTERLINE, 81 FT MSL.
TREE 644 FT FROM DER, 474 FT LEFT OF CENTERLINE, 49 FT MSL.
TREES BEGINNING 693 FT FROM DER, 291 FT RIGHT OF CENTERLINE, UP TO
91 FT MSL.
TREES BEGINNING 745 FT FROM DER, 486 FT LEFT OF CENTERLINE, UP TO
86 FT MSL. 2304041758-2504041758EST
END PART 2 OF 3
!FDC 3/6045 W41 PART 3 OF 3 ODP CRISFIELD-SOMERSET COUNTY,
CRISFIELD, MD.
62 FT MSL.
TREES BEGINNING 881 FT FROM DER, 449 FT LEFT OF CENTERLINE, UP TO
79 FT MSL.
TREES BEGINNING 967 FT FROM DER, 170 FT LEFT OF CENTERLINE, UP TO
86 FT MSL. 2304041758-2504041758EST
END PART 3 OF 3
|
